Axis angle measurement, angle sensor G36
FEATURES:
◆Capacity: ±50º
◆Dual axis angle measurement
◆Compact size, light weight, easy installation and quick response
Description
SPECIFICATION:
| PARAMETER | VALUE | PARAMETER | VALUE | |
| Rated capacity | ±50º | Operating temperature range | -40～+125℃ | |
| Recommended Excitation | 24±12 VDC | Material | Die-Cast aluminum | |
| Current consumption | <100 mA | Environment protection | IP67 | |
| Dual signal output (choose one of three options) |
Analog output | 4～20mA | Climate test | EN60068-2-30,DB55℃/100% |
| CAN Bus | CAN open, CAN open Safety |
Vibration resistance | EN60068-2-6,5-500Hz,50g,10mm | |
| Wireless Network | ZigBee/LoRa/NB-IOT | Shock resistance | EN60068-2-27(half sine) 50g,11ms,1000shocks; 1000g,1ms,50shocks |
|
| Combined error | 1%FS | |||
